ask a questionAfter many years of Combined Centrifuge-Vortex concept success, we are proud to introduce the long awaited Centrifuge/Vortex for PCR plates, CVP-2, to the sample preparation market.
The Spin–Mix–Spin technology is intended to spin-down micro volumes of reagents on the well's bottom (first centrifugation spin), following mixing (mix) and spin-down the reagents again from the walls and cap of the well (second spin). We named this repetitive algorithm of operation that is aimed at reducing the mistakes during sample preparation for PCR analysis a “sms–algorithm”. This algorithm is registered by Biosan.
CVP-2 is a fully automatic device for reproducing sms–algorithm for 2 PCR plates at the same time, thus saving time considerably. A must-have instrument for PCR and DNA analyses laboratory.
CVP-2 is 4 devices combined in 1:
- Centrifuge — Maximum RCF: 225 × g (1500 rpm)
- Vortex (300–1200 rpm; Vortexing regulation timer 0–60 sec)
- Centrifuge/Vortex
- SMS–cycler for realization of the “sms–algorithm”
Plate type:
Without adapter:
96-well skirted PCR plates, PCR strips in a frame;
With adapter AP-96*:
96-well semi-skirted and non-skirted PCR plates;
With adapter AP-384*:
384-well PCR plates;
* - Adapters are made of Ertacetal® C. Autoclavable
SMS-cycle regulation | 1 - 999 cycles |
---|---|
Speed regulation range | 300–1500 rpm |
Min. RCF at 1500 rpm | 185 x g |
Vortex regulation range | 300–1200 rpm |
Setting resolution | 100 rpm |
Timer sound signal | + |
Display | LCD, 2 x 16 signs |
Centrifugation mode time range | 0–30 min (increment 1 s; after 1 min - 1 min) |
Vortex mode time range | 0–60 sec (increment 1 sec) |
Chamber diameter | 210 mm |
Overall dimensions (W×D×H) | 285 × 350 × 190 mm |
Weight | 6.15 kg |
Input current/power consumption | 12 V, 1.5 A / 18 W |
External power supply | Input AC 100–240 V; 50/60 Hz; Output DC 12 V |
-
2 adapters for 96-well semi-skirted and non-skirted PCR plates - made of Ertacetal® C. Autoclavable
